Mechrail™ crane system

The Swedish-designed Mechrail™ overhead crane system in strong and lightweight aluminium offers many smart features for ergonomic and flexible material handling.

Ergonomiskt traverssystem i aluminium Mechrail
Mechrail™ lättraverssystem med smarta tillbehör - traverssystem-kransystem-skensystem-travers-Movomech
c
Mechrail™ lättraverssystem - traverssystem-kransystem-skensystem-travers-Movomech
Mechrail™ lättraverssystem med smarta tillbehör - traverssystem-kransystem-skensystem-travers-Movomech
Mechrail™ lättraverssystem med självbärande skarvsats - traverssystem-kransystem-skensystem-travers-Movomech
Mechrail™ lättraverssystem med lågt rullmotstånd traverssystem-kransystem-skensystem-travers-Movomech
Kransystem Mechrail profiler 2019

Mechrail™ crane system

Mechrail™ aluminium crane system

Movomech has decades of experience of lightweight crane systems made from extruded aluminium profiles, and we were one of the first in the world to explore the benefits of aluminium as a material for crane system solutions. Aluminium is a strong, lightweight material, and when anodized it is maintenance-free.

Minimal rolling resistance for optimal ergonomics

The aluminium profiles in the Mechrail™ system have been designed for maximum strength and torsional rigidity combined with a very low tare weight, making Mechrail™ a very easy-to-use and ergonomic crane system. The starting force and the rolling resistance experienced by the operator during handling are among the absolute lowest on the market.

Expandable profiles for tailormade design

The Mechrail™ aluminium crane system is easy to install and expand or supplement as needed.

Specification and application areas

The Mechrail™ crane system profiles are made of anodized aluminium and require no maintenance. They are manufactured from EN-AW 6063 T6 aluminium alloy according to SS-EN 755-2:2016, anodized colour C0 (natural). This product is designed to be used indoors in typical industrial environments such as in the automotive industry, production and general manufacturing.

Product features
  • Very low rolling resistance for ergonomic handling
  • Meets the strict ergonomics and accessibility requirements of the automotive industry
  • Wide range of smart accessories
  • Easy to assemble
  • Modular design for easy expansion
  • Swedish design
  • Assortment developed in collaboration with installers and operators
  • Customized to the desired design
  • Easily dimensioned with ECONFIG™ configurator



Do you want to know more?

Are you interested in this product? Fill out the form and we will get in touch with you.

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.
Applications

Do you want to know more?

Are you interested in this type of handling solution? Fill out the form and we will get in touch with you.

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.
Related files
VERSION
PHB
LHB
PHB1
AHB140
AHB190
AHB3
Product series
30s
30s
50s
50s
50s
75s
Profile length
m
1 - 6
1 - 7.7
1 - 7
1 - 8
1 - 8
1 - 7.7
Max load
kg
63
250
320
500
500
1000
Weight
kg/m
1.6
3.7
4.0
7.0
8.2
11.2
